RocketLinx ® ES7206-XT - Unmanaged PoE Plus Industrial switch, with four Gigabit 802.3af/at PoE ports, one copper Gigabit uplink port and one Gigabit fiber SFP port. This rugged 6-port Gigabit PoE Plus Switch is built for harsh conditions and will operate from -40°C to 75°C.The RocketLinx ES7206-XT is an industrial-grade, 802.3af/at PoE Plus switch designed for integration of mission-critical PoE devices in IP security, access control, in-vehicle, and intelligent transportation systems.
The ES7206-XT features four Gigabit speed, high-power 802.3af/at ports, Gigabit copper and SFP fiber uplink ports, and a full 120W power budget for maximizing PD power delivery to devices such as PTZ cameras.
A compact, DIN rail mount housing, extended operating temperature, and wide 12-36V input voltage range enable the ES7206 to satisfy the widest variety of PoE integration requirements.
DIN rail mounting bracket included.
Features
- Unmanaged, ìPlug and Playî installation for quick setup and deployment
- Four (4) Gigabit IEEE 802.3af/at PoE ports
- One (1) Gigabit copper uplink port
- One (1) SFP uplink port supporting multi-mode or single-mode fiber connections
- Voltage Boost Technology enabling direct 12-36 VDC input supporting vehicle/access control/factory electrical systems
- 9KB jumbo frame support with wire speed performance
- User configurable multi-event alarm relay
- Rugged industrial design with IP30 steel housing
- IP30 rugged steel housing
- -40°C to 75°C extended operating temperature range for deployment in harsh environments
- Ideal for IP surveillance, rail, transit, traffic, mining, and other demanding PoE applications
- DIN rail installation (bracket included)
