IoT business automation requires communication with various IT assets and peripherals located across an enterprise. AnywhereUSB® Plus remote USB hubs give users the simplest and most direct connection options for existing equipment with a variety of USB 3.1 Gen 1 port options. All three models have Gigabit Ethernet support for failover redundancy and network bonding with SFP+ ports in the 8 and 24-port models for higher speeds or fiber networks.
AnywhereUSB 24 Plus is rack mountable with 24 USB 3.1 Gen 1 ports, while AnywhereUSB 8 Plus and AnywhereUSB 2 Plus are desktop or panel mountable units with eight or two ports, respectively, and support for Gigabit Ethernet.
AnywhereUSB can be coupled with Digi Remote Manager®, a web-based device configuration and security management platform, to help users reduce downtime. An intuitive user experience makes installation smooth and easy; with quick setup and configuration to monitor and maintain larger installations of remote Digi and third-party devices.
For enterprise and industrial customers who need remote or local USB ports and the higher speeds of USB 3.1 Gen 1 and Gigabit/10 Gigabit Ethernet, Digi AnywhereUSB Plus products give you an industry-leading connectivity solution.
Documentation
Data Sheet- Userís Guide
| Specifications | AnywhereUSB® 2 Plus | AnywhereUSB® 8 Plus | AnywhereUSB® 24 Plus |
|---|---|---|---|
| CELLULAR | |||
| MODULE SUPPORT | - | (1) Digi CORE modem compliant socket | (1) Digi CORE modem compliant socket |
| SOFTWARE AND MANAGEMENT | |||
| REMOTE MANAGEMENT | Digi Remote Manager® (cloud based) | ||
| LOCAL MANAGEMENT | WebUI (HTTP/HTTPS); CLI (SSH) | WebUI (HTTP/HTTPS); CLI (Console, SSH) | WebUI (HTTP/HTTPS); CLI (Console, SSH) |
| MEMORY | 512MB RAM, 4GB flash (eMMC) | 2GB RAM, 4GB flash (eMMC) | 2GB RAM, 4GB flash (eMMC) |
| NETWORK | |||
| ETHERNET | (1) RJ-45; 10/100/1000 Mbps | (1) RJ-45; 10M/100M/1G/10G Ethernet | (2) RJ-45; 10M/100M/1G/10G Ethernet |
| SFP+ | - | (1) SFP+ socket | (2) SFP+ sockets |
| CONNECTORS | |||
| CONSOLE | - | (1) DB09M; RS232 DTE | |
| USB | (2) USB 3.1 Gen 1 Type A | (8) USB 3.1 Gen 1 Type A | (24) USB 3.1 Gen 1 Type A |
| PHYSICAL | |||
| DIMENSIONS (L X W X H) | 4.6 in x 2.9 in x 1.2 in (118 mm x 74 mm x 30 mm) | 10 in x 6 in x 1.75 in (260mm x 160 mm x 44.45 mm) | 17.75 in x 10 in x 1.75 in (450.85 mm x 255 mm x 44.45 mm) |
| WEIGHT | 0.84 lb (0.38 kg) | 3.48 lb (1.58 kg) | 10.36 lb (4.7 kg) |
| STATUS LEDS | (2) Ethernet, 2 (x1) USB, power | (2) Ethernet, (2) SFP+ 8 (x1 )USB, power, fan, user, (3) future Wi-Fi/WWAN | 2 (x2) Ethernet, 2 (x2) SFP+, 24 (x1) USB, 2 (x1)PSU, 2 (x1) fan, user, (3) future Wi-fi/WWAN |
| POWER REQUIREMENTS | |||
| POWER INPUT | 5V, 5A max | 12V DC, 12A max | 100-240V 3A Max (2 supplies for redundancy) |
| POWER CONSUMPTION | 25 watts max | 98.5 watts max | 157.7 watts max |
| ENVIRONMENTAL | |||
| OPERATING TEMPERATURE | 32 ∞F to +104 ∞F (0 ∞C to +40 ∞C) | 32 ∞F to +131 ∞F (0 ∞C to +55 ∞C) | 32 ∞F to +131 ∞F (0 ∞C to +55 ∞C) |
| RELATIVE HUMIDITY | 5% to 95% (non-condensing) | 5% to 95% (non-condensing) | 5% to 95% (non-condensing) |
| APPROVALS | |||
| BLUETOOTH | - | Bluetooth BLE 4.2 | |
| SAFETY | UL 60950, CSA 22.2 No. 60950, EN60950, EN62368 | UL/EN60950, UL/EN62368 and CSA 22.2 | UL 60950, CSA 22.2 No. 60950, EN60950, EN62368 |
| EMISSIONS/IMMUNITY | CE, FCC Part 15 Class B, AS/NZS CISPR 22, EN55024, EN55032 | CE, FCC Part 15 Class B, AS/NZS CISPR 22, EN55024, EN55032 | CE, FCC Part 15 Class B, AS/NZS CISPR 22, EN55024, EN55032 |
| WARRANTY | |||
| PRODUCT WARRANTY | 5 years | ||
Features
- Network-attached USB hubs easily connect USB peripheral devices to a PC from remote or virtual hosts
- Ideal for connecting USB devices over the network in virtualized environments such as VMware®
- AnywhereUSB 24 Plus is rack mountable with two built-in power supplies and two Ethernet connections for failover redundancy
- Access and monitor USB and serial devices over TCP/IP connection
- Includes Digi Remote Manager® cloud-based management platform to deploy, monitor, manage and maintain a suite of peripherals and devices
- 1 Year LifeCycle Assurance with 24x7 Expert Support and Digi Remote Manager Premier included
