The DA-681C computer is built around an Intel® Celeron® or Intel® Core™ i3 CPU and comes with dual display ports (2 x HDMI), 5 USB ports, 6 Gigabit LAN ports, two 3-in -1 RS-232/422/485 serial ports, 10 RS-485 serial ports, 6 digital input ports, and 2 digital output ports.
Additionally, one 2.5” HDD/SSD slot and one mSATA slot are included to enable storage expansion for industrial applications that require large storage space for edge data acquisition.
MOXA
Moxa x86 1U Rackmount IEC 61850-3 computer w/ Intel Celeron 3965U [2.2 GHz], (2) HDMI, (5) USB, (6) Gigabit LAN, (2) 3-in-1 RS232/422/485, (10) RS485, (6) DI, (2) DO & single power 100 to 240 VAC/VDC [w/o RAM/SSD/OS] (xtemp)
MOXA
Moxa x86 1U Rackmount IEC 61850-3 computer w/ Intel Celeron 3965U [2.2 GHz], (2) HDMI, (5) USB, (6) Gigabit LAN, (2) 3-in-1 RS232/422/485, (10) RS485, (6) DI, (2) DO & dual power 100 to 240 VAC/VDC [w/o RAM/SSD/OS] (xtemp)
MOXA
Moxa x86 1U Rackmount IEC 61850-3 computer w/ Intel Core i3-7100U [2.4 GHz], (2) HDMI, (5) USB, (6) Gigabit LAN, (2) 3-in-1 RS232/422/485, (10) RS485, (6) DI, (2) DO & dual power 100 to 240 VAC/VDC [w/o RAM/SSD/OS] (xtemp)
