The EDS-405A-PTP are 5-port IEEE 1588v2 PTP switches designed especially for real-time control applications. The switches support Modbus TCP, PROFINET RT, and EtherNet/IP for better SCADA integration. Other management functions such as IGMP snooping, IEEE 802.1Q VLAN, QoS, RMON and relay warning, make the network planning more flexible and easy.IEEE 1588 PTP Features
ï IEEE 1588v2 PTP (Precision Time Protocol) with hardware time stamping for precise time synchronization of networks
ï Support both IEEE 1588 Boundary Clock and Transparent Clock
ï Support both End to End (2-step) and Peer to Peer (2-step) modes in Transparent Clock
ï High precision time accuracy (under 1 μs)
Documentation
Features
ï Command Line Interface (CLI) for quickly configuring major managed functionsï DHCP Option 82 for IP address assignment with different policies
ï Support EtherNet/IP, Modbus/TCP and PROFINET protocols for device management and monitoring
ï Turbo Ring and Turbo Chain (recovery time < 20 ms @ 250 switches), and RSTP/STP for network redundancy
ï IGMP snooping and GMRP for filtering multicast traffic
ï Port-based VLAN, IEEE 802.1Q VLAN, and GVRP to ease network planning
ï QoS (IEEE 802.1p and TOS/DiffServ) to increase determinism
ï RMON for efficient network monitoring and proactive capability
ï SNMPv1/v2c/v3 for different levels of network management security
ï Bandwidth management to prevent unpredictable network status
ï Port mirroring for online debugging
