Name: ICDM-RX-MOD-2DB9-RJ45-DIN
Brand: Comtrol
SKU: ICDM-RX-MOD-2DB9-RJ45-DIN
Price: 485.48 USD
Availability: InStock

Pepperl+Fuchs Comtrol DeviceMaster 2 Port Serial Gateway, Modbus TCP/IP w/(2) RS232/422/485 DB9M, (1) RJ45 10/100 & Screw Terminal Power (DIN Rail Mount)

0 Read Reviews

| Code: ICDM-RX-MOD-2DB9-RJ45-DIN

Price: $485.48

Retail $562.87

$77.39

Free Shipping Included Usually Ships in 24 Hours; Contact Sales to Verify

About This Item

Overview

Details

Modbus Gateway 2-port DIN rail DB9

The ICDM-RX/MOD product family provides an innovative network-wide Modbus connectivity from a wide variety of Modbus masters to a wide variety of local and remote Modbus slaves. Advanced features include master-to-master communication, private serial bus connectivity, write protection, and device ID aliasing. With simplified configuration pages and advanced routing, it provides unmatched Modbus connectivity. The integrated webserver enables complete configuration of all module parameters like serial interface, baud rate, data bits, stop bits, or flow control.

Products are available in different versions for DB9 or screw terminal connection.

Features

DIN-rail mounting and DB9 connectors Pure Modbus, multiple Modbus master and slave types , remote, local, and private devices Web-based configuration RS-232/422/485 software selectable interfaces NEMA TS2 Certified
