About This Item
Overview
Details
Industrial cellular router ICR-2041 is designed for wireless
communication to enable connection of IP devices to a cellular network.
Industrial M2M and IoT applications include kiosks, industrial PCs, HMIs,
traffic controllers, meters, UPS systems, and much more. The peak downlink data
rate for LTE Cat.4 is approximately 150 Mbps. Also in the uplink, LTE Cat.4
provides a peak data rate of 50 Mbps.
The router is equipped with one Ethernet port (LAN) and with
digital I/O connectivity (1x DI, 1x DO). The router supports VPN tunnel
creation using various protocols to ensure safe communications. The router
provides diagnostic functions which include automatic monitoring of the
wireless and wired connections, automatic restart in case of connection losses,
and a hardware watchdog that monitors the router status.
Router is based on ICR-OS operation system. Open Linux
platform enable wide possibilities of programming customer SW applications in
Python, C/C++. Router supports uploading of RouterApps that would extend
standard firmware functionalities. Existing app library ready for free download
by customer contains already developed software apps to enhance specific router
functionality including industrial protocol conversions, support of IoT
platforms such as MS Azure, Cumulocity, ThingWorx and a lot more.
Documentation
Features
- LTE
Cat.4 with 3G fallback
- 1◊ SIM
- 1◊
Ethernet, RJ45, 10/100 Mbps
- 1◊ DI,
1◊ DO
- Wide
operational temperature range
- Wall
and DIN mount options
- Linux
based OS & SW customization
- Carriers
support: Verizon, AT&T, T-Mobile
