The versatility and performance of Digi® WR54 routers make them ideal for mission critical applications requiring continuous connectivity, field longevity and edge computing. FirstNet Readyô Digi WR54 provides secure routing and gateway functions across wired and wireless communication networks. Local private subnets are bridged across public networks to safeguard privacy and integrity.Digi WR54 is available with dual Wi-Fi radios to segment passenger Wi-Fi from fare collection, data, video and oher applicationos, and offers FirstNet Ready models with both single and dual cellular modules. FirstNet® is a public/private partnership managed by the U.S. Dept. of Commerce that develops adn operates a nationwide first responder network.
Designed to meet the demands of first responders, Digi WR54 includes concurrent and independent dual cellular interfaces that prioritize critical communications. Industrial-grade design supports the most rugged conditions, including vibration and temperature changes. An embedded Python environment also enables quick adaptation to evolving system requirements.
Four Gigabit Ethernet ports connect other IP-capable systems, each configurable as an isolated secure LAN, or all four can function as a Layer 2 switch. Digi TrustFence®, a suite of hardware and firmware features, ensures the integrity of Digi WR54 security functions. A cryptographic co-processor protects particularly sensitive information.
Documentation
- PDF Hardware Reference
- PDF User Guide
| SPECIFICATIONS | Digi WR54 |
|---|---|
| CELLULAR | |
| LTE – WORLDWIDE |
LTE FDD: B1, B2, B3, B4, B5, B7, B8, B12, B13, B17, B20, B25, B26, B28, B29, B30 (Rx only), B66; LTE TDD: B38, B40, B41
3G HSPA+: B1, B2, B4, B5, B8 Transfer rate (max): 600 Mbps down, 75 Mbps up (Cat 11) |
|
LTE – UNITED STATES / CANADA
(FIRSTNET READY) |
LTE FDD : B1, B2, B3, B4, B5, B7, B8, B9, B12, B13, B14, B18, B19, B20, B26, B29, B30, B32, B41, B42, B43, B46, B48, B66
3G HSPA: B1, B2, B4, B5, B6, B8, B9, B19 Transfer rate (max): 600 Mbps down, 150 Mbps up (Cat 12) |
| CONNECTOR |
Single cellular models: (2) 50 Ω SMA (center pin: female)
Dual cellular models: (4) 50 Ω SMA (center pin: female) |
| SIM SLOTS |
Single cellular models: (2) Mini-SIM (2FF)
Dual cellular models: (4) Mini-SIM (2FF) |
| SIM SECURITY | Screw-down SIM cover |
| WI-FI | |
| MODULE | 2 x 2 MIMO 2.4/5 GHz 802.11 a/b/g/n/ac, 867 Mbps (max); dual Wi-Fi modules in WR54-A112 |
| HOTSPOT | Captive portal, customizable splash page |
| AUTHENTICATION | Basic ToS acceptance, Enterprise RADIUS |
| 3RD PARTY SERVICES | Content filtering, embedded advertising |
| USER MANAGEMENT | Per client usage limit and reporting |
| MODES | Up to 4 access points and 1 client per Wi-Fi module (8+2 total) |
| SECURITY | None, WPA/WPA2-personal, WPA/WPA2-enterprise |
| CONNECTORS | 2 x 50 Ω RP-SMA (center pin: male) |
| GPS | |
| TECHNOLOGY | Multi-constellation: concurrent reception of up to 3 GNSS (GPS, Galileo, GLONASS, BeiDou) |
| SENSITIVITY | -163 dB |
| PROTOCOL | Protocol NMEA 0183 V2.3 sentence output |
| CONNECTOR | 1 x 50 Ω SMA (center pin: female); +3.3 VDC active antenna drive |
| SOFTWARE AND MANAGEMENT | |
| PROTOCOLS | IPv4/IPv6, DMNR, QoS, NTP, Dynamic DNS, Syslog |
| SECURITY | Stateful firewall, VPN (IPsec and OpenVPN), PKI and RADIUS |
| REMOTE MANAGEMENT | Digi Remote ManagerÆ (cloud based); SNMP v1/v2c/v3 |
| LOCAL MANAGEMENT | Web interface (HTTP/HTTS); CLI (SSH, serial port) |
| MANAGEMENT/ TROUBLESHOOTING TOOLS | Protocol analyzer with PCAP for Wireshark, event and system logging (with Syslog), accessible from Digi Remote Manager, SFTP or SCP |
| PROGRAMMING TOOLS/ ENVIRONMENTS | Python v3.5 |
| ETHERNET | |
| PORTS | (4) RJ-45; 10/100/1000 Mbps (auto-sensing) |
| SERIAL | |
| PORTS |
(1) DB9-M; RS-232 DTE
Signal support TXD, RXD, RTS, CTS, DTR, DCD, DSR, RI software (XON/XOFF), hardware supported |
| USB | |
| PORTS | (1) USB 3.0 Type A connector |
| PHYSICAL | |
| DIMENSIONS (L X W X H) | 14.61 cm x 20.95 cm x 6.35 cm (5.75 in x 8.25 in x 2.5 in) |
| WEIGHT | 1.5 kg (3.3 lbs) |
| STATUS LEDS | Power on, WWAN signal strength, WWAN service |
| ENCLOSURE | Die-cast aluminium / IP54 |
| POWER REQUIREMENTS | |
| POWER INPUT | 9 - 36 VDC, 30 W minimum power source required |
| POWER CONSUMPTION | 13 W typical (idle); 20 W typical (peak Tx/Rx) |
| ENVIRONMENTAL | |
| OPERATING TEMPERATURE | -34∞ C to 74∞ C (-29∞ F to 165∞ F) |
| RELATIVE HUMIDITY | 5% to 95% (non-condensing) |
| APPROVALS | |
| CELLULAR | PTCRB, AT&T, Sprint (WR54-A146 and WR54-A246 only), Verizon |
| SAFETY | EN60950, EN62368 |
| VEHICLE | ISO 7637-2/3, ISO 10605, ISO 16750-2 Pulses 4/5a/5b, SAE J1455, SAE J1113, E-Mark* |
| ENVIRONMENTAL | MIL-STD-810G |
| EMISSIONS/IMMUNITY | CE, FCC Part 15 Class B, AS/NZS CISPR 22, EN55024, EN55032 |
| WARRANTY | |
| PRODUCT WARRANTY | 3-year product warranty (1-year Digi Foundations Included)** |
Features
- FirstNet Ready models Digi WR54 A146/A246 with single or dual cellular modules
- Global models Digi WR54 A106/A206 with single or dual cellular radios
- Future-built with dual-core 880 MHz MIPS processor and PCIe 2.0 internal bus
- Segmented private vs. public data communication across dual 600 Mbps Cat 11 cellular modules
- High-speed 867 Mbps 802.11ac Wi-Fi for WAN or LAN service and dual Wi-Fi radios in Digi WR54-A112
- Cryptographic co-processor with secure key generation
- Gigabit WAN/LAN Ethernet switch (4-port)
- Zero-touch configuration using Digi Remote Manager®
- Digi Foundationsô 1-, 3- or 5-year subscription included
